Big boats, small boats, cruisers, weekender, racers…
If you use shackles or snap hooks on your boat, ROBSHIP Soft Shackles will make your life easier and simpler
Lots of features that can’t be found in metal shackles!
- About the same price as stainless steel shackles but with more advantages
- Lightweight: 4-6 times lighter than equivalent stainless steel shackles (they float!)
- Soft & safer than metal shackles: no damage to deck-side, other equipment, or people
- Can be threaded through narrow gaps, where metal shackles can’t go through
- Easy to use, very simple to open & close (no tools like shackle opener required)
- No fiddling with bits that can fall out
- Extremely strong: UV stabilized & abrasion resistant Dyneema used
From choosing materials to manufacturing
We only use Ocean 3000 XG braided by FSE Robline, a rope manufacturer with over 250 years of history that uses high quality DSM Dyneema. The Ocean 3000 XG is a Dyneema SK78 with an upgraded coating to ensure good UV stability and enhances its abrasion resistance. Only our experienced professional team is involved in the production of soft shackles. The line sizes are abundant so that each line size can be used appropriately for its intended purpose. Machine stretching is applied during the manufacturing process to make the soft shackles compact and strong. Soft shackles can be made by hand relatively easily, but soft shackles produced through this development and manufacturing process are uniquely different from handmade products. The coloring of the raw material is resistant to fading, and the PU coating on the material rope prevents being held up and feathering.
| Size | 2mm | 2.5mm | 3mm | 4mm | 5mm | 6mm | 8mm | 10mm |
|---|---|---|---|---|---|---|---|---|
| Breaking Strength | 451kg (994lbs) | 850kg (1875lbs) | 1372kg (3025lbs) | 1635kg (3605lbs) | 2993kg (6598lbs) | 4023kg (8870lbs) | 5900kg (13000lbs) | 7000kg (15400lbs) |
| Weight load | 225kg (496lbs) | 425kg (936lbs) | 663kg (1461lbs) | 817kg (1801lbs) | 1496kg (3298lbs) | 2011kg (4433lbs) | 2950kg (6500lbs) | 3500kg (7700lbs) |
| Safe load | 90kg (198lbs) | 170kg (374lbs) | 274kg (604lbs) | 327kg (720lbs) | 599kg (1320lbs) | 804kg (1772lbs) | 1180kg (2600lbs) | 1400kg (3086lbs) |
| Material rope dia. | 2mm (5/64") | 2.5mm (3/32") | 3mm (1/8") | 4mm (5/32") | 5mm (3/16") | 6mm (1/4") | 8mm (5/16") | 10mm (3/8") |
| dia. (D) | 3.5mm (9/64") | 4mm (5/32") | 5mm (3/16") | 6.5mm (1/4") | 7.5mm (19/64") | 9.5mm (3/8") | 11.5mm (7/16") | 15.5mm (5/8") |
| thickness (F) | 2.7mm (7/64") | 3mm (1/8") | 4mm (5/32") | 5mm (3/16") | 5.5mm (7/32") | 6.5mm (1/4") | 9.5mm (3/8") | 12mm (15/32") |
| dia. (H) | 8mm (5/16") | 9mm (23/64") | 11mm (7/16) | 15mm (19/32) | 18mm (23/32") | 22mm (7/8") | 29mm (1 3/16") | 37mm (1 1/2") |
| Loop size (L) | 20 / 40 / 60 80 / 100mm | 20 / 40 / 60 80 / 100mm | 20 / 40 / 60 80 / 100mm | 40 / 60 / 80 100 / 150mm | 40 / 60 / 80 100 / 150mm | 40 / 60 / 80 100 / 150mm | 60 / 80 100 / 150mm | 80 / 100 150mm |
| 7/8, 1 9/16, 2 3/8, 3 1/8, 4" | 7/8, 1 9/16, 2 3/8, 3 1/8, 4" | 7/8, 1 9/16, 2 3/8, 3 1/8, 4" | 1 9/16, 2 3/8, 3 1/8, 4, 6" | 1 9/16, 2 3/8, 3 1/8, 4, 6" | 1 9/16, 2 3/8, 3 1/8, 4, 6" | 2 3/8, 3 1/8, 4, 6" | 2 3/8, 3 1/8, 4, 6" |
- anchor/shackle size: inner dimension when the loop of each part is elongated
- loop size: inner dimension when the loop of each part is elongated while the shackles are closed
